ZGLOADER / MYZG DY26 Low-Profile Underground Wheel Loader

ZGLOADER / MYZG DY26 Low-Profile Underground Wheel Loader

The ZGLOADER / MYZG DY26 is a compact, low-profile underground wheel loader for tunnels, mines, hydropower galleries, basements and confined material-handling areas. Its approximately 2220 mm overall height, articulated steering and compact body help it work where a conventional high-cab loader has limited clearance.

Engineered for superior performance in material handling and construction operations, the DY26 compact wheel loader stands out with its remarkable 1380kg load capacity and 0.6 cubic meter bucket capacity. This versatile machine demonstrates exceptional operational capabilities across diverse working environments, from construction sites to agricultural settings. With an operating weight of 3200kg, it maintains perfect balance between stability and maneuverability, ensuring reliable performance during intensive working cycles. The heart of this equipment is the powerful Quanchai 4B2-75M22 engine, delivering 55kW rated power at 2400 rpm, providing ample power for the most demanding tasks. Measuring 5530*1940*2220mm, its compact dimensions enable efficient operation in confined spaces where larger machinery would struggle. The impressive 3000mm dump height combined with 400mm dump distance facilitates efficient truck loading and container handling, significantly enhancing productivity across various job sites.

Outstanding maneuverability represents one of the key strengths of this wheel loader, achieved through its optimized 3635mm minimum turning radius. The carefully engineered 2430mm wheelbase and 1490mm wheeltrack work in harmony to deliver exceptional stability and agility. Equipped with 20.5/70-16 tires, the machine maintains excellent traction and stability across diverse surfaces, from smooth concrete floors to challenging rough terrains. The Quanchai diesel engine not only provides reliable power output but also ensures remarkable fuel efficiency and environmentally friendly operation, complying with modern emission standards. The ergonomically designed operator cabin features intuitively arranged controls and offers excellent visibility, significantly reducing operator fatigue during extended working sessions. The advanced hydraulic system ensures smooth and precise operation, enabling accurate material handling and placement with exceptional control.

In practical application scenarios, this robust loader proves its worth across multiple industries. Construction sites benefit from its ability to efficiently handle various materials including sand, gravel, and concrete, while its compact design allows easy navigation through narrow passages and confined working areas. Agricultural operations utilize the machine for handling animal feed, fertilizers, and harvested crops with equal efficiency. The generous 3000mm dump height enables convenient loading into trucks and storage facilities, while the 400mm dump distance ensures safe and efficient unloading operations. Industrial applications see the loader excelling in warehouse management and manufacturing facilities, moving materials with precision and reliability. The combination of 1380kg load capacity and 0.6m³ bucket capacity makes it suitable for handling diverse materials, from lightweight bulk items to heavier aggregates, demonstrating remarkable versatility across different working conditions and terrain types.

Durability and maintenance efficiency form the cornerstone of this loader's design philosophy. The Quanchai powerplant is renowned for its reliability and straightforward maintenance requirements, ensuring minimal operational downtime and reduced running costs. Constructed using high-quality materials and robust engineering principles, the machine guarantees extended service life even under the most demanding working conditions. strategically placed maintenance points facilitate easy access for routine checks and servicing procedures. Comprehensive safety features protect both the operator and equipment, incorporating stability enhancement systems and emergency safety mechanisms. This combination of performance excellence, operational reliability, and cost-effectiveness makes the DY26 an outstanding investment for businesses seeking to enhance their material handling capabilities while maintaining high efficiency standards and optimizing operational costs.

The DY26 combines a 1380 kg rated load with a 0.6 m3 bucket, 3200 kg operating weight and QUANCHAI 4B2-75M22 diesel engine rated at 55 kW. A maximum dump height of 3000 mm supports loading into suitable underground transport vehicles and stockpile work. The JINLITE 265 transmission and articulated chassis provide controllable direction changes and traction on prepared underground haul routes.

Typical duties include removing excavated soil, moving broken rock within rated capacity, loading small trucks, maintaining tunnel headings, handling construction materials and supporting utility installation. The low-profile underground loader can also work in industrial buildings or agricultural structures with restricted headroom. Material density, gradient, ventilation, ground condition and vehicle height should be provided so the bucket and safety package can be matched correctly.

Underground operation requires site-specific risk assessment. The standard diesel DY26 must not be described as explosion-proof unless the ordered configuration has the necessary certified components. Ventilation, lighting, braking, fire suppression, exhaust treatment, operator protection and local mining regulations must be reviewed by the buyer. Operators should travel with the bucket low, avoid abrupt steering on slopes and never exceed the rated load.

Daily inspection should cover engine oil, coolant, hydraulic fluid, tyres, articulation pins, hoses, bucket welds, brakes, lights and warning devices. Dust and debris should be removed from the radiator and engine compartment to preserve cooling. ZGLOADER / MYZG can discuss optional work lights, protective structures, attachments, service parts, shipping and the current factory quotation for the DY26 underground loader.

Shandong Zhuogong Machinery equipment Co.,Ltd supplies ZGLOADER / MYZG DY26 underground loaders. Contact us for configuration, attachments, safety options, warranty, shipping and quotation.
