3.8 Ton Backhoe Loader 75KW Yuchai Engine 1.2m³ Bucket
The 388H Backhoe Loader stands as a formidable and highly versatile earthmoving solution, meticulously engineered to tackle the most demanding challenges across construction, utility, and agricultural sectors. With a robust overall operating weight of 10,300 kg, this machine delivers exceptional stability and power for a wide range of heavy-duty applications. At the heart of its performance lies a powerful and reliable 75 KW Yuchai engine, renowned for its fuel efficiency, low emissions compliance, and dependable power output that ensures consistent productivity even under the most strenuous working conditions. The machine's substantial dimensions of 6450x2500x3940 mm provide a solid and balanced platform, contributing to its operational safety and impressive lifting capabilities. Designed for maximum versatility, the 388H is not just a simple digger; it is a multi-talented workhorse capable of deep excavation, efficient loading, precise lifting, and agile maneuvering, all consolidated into a single, cost-effective piece of equipment. Its design philosophy centers on delivering unparalleled performance metrics, including a significant bucket dumping height and a substantial digging depth, making it an indispensable asset for any serious contractor looking to maximize efficiency and return on investment on the job site. This machine represents the perfect synergy of raw power, intelligent design, and operational flexibility.
The loading and excavation capabilities of the 388H Backhoe Loader are where its true potential is unleashed, setting a new benchmark for productivity in its class. The front loader is equipped with a generously sized 1.2 cubic meter bucket, specifically designed for high-volume material handling tasks such as loading trucks, moving bulk aggregates, and site clearing with remarkable speed and efficiency. This is complemented by an impressive bucket dumping height of 3050 mm, allowing operators to easily clear the sides of large dump trucks and high stockpiles, thereby streamlining the loading process and minimizing cycle times. Furthermore, the loader arm boasts a substantial loading lifting capacity of 2500 kg, enabling the machine to handle heavy pallets, pipes, and construction materials with ease and confidence. On the opposite end, the backhoe features a robust 0.3 cubic meter capacity bucket, optimized for powerful digging and trenching operations. The standout feature of the backhoe is its maximum digging depth of 3820 mm, enabling it to tackle deep foundation work, utility trenching, and drainage projects without requiring larger, more specialized excavators. This combination of a high-capacity loader and a deep-digging backhoe makes the 388H an incredibly self-sufficient machine, capable of performing a complete cycle of excavation and material relocation on its own.
Maneuverability and operational precision are critically enhanced by the 388H's advanced steering system and stable chassis design, ensuring superior performance in confined and complex work environments. The machine is outfitted with a sophisticated four-wheel steering system, providing the operator with the flexibility to choose between standard rear-wheel steering for high-speed travel, coordinated front and rear steering for exceptionally tight turning circles, and crab steering for unparalleled sideways movement. The crab walk feature, in particular, is invaluable for working along trenches, foundations, or walls without constantly repositioning the machine, thereby saving significant time and reducing operator fatigue. A wheelbase of 2335 mm strikes an optimal balance between stability during lifting and digging operations and overall agility when navigating around the job site. The machine rides on large, industrial-grade 16.9-28 tires, which offer excellent traction and flotation on a variety of terrains, from soft soil to rough construction sites. This exceptional maneuverability, combined with the precise hydraulic controls for both the loader and backhoe, allows operators to work with confidence and accuracy in the most spatially restricted and challenging project sites, from dense urban developments to complex industrial plant maintenance.
OVERALL OPERATING WEIGHT
10300KG
DIMENSIONS
6450x2500x3940MM
WHEEL BASE
2335MM
BUCKET DUMPING HEIGHT
3050MM
BUCKET DUMPING DISTANCE
870MM
MAX.DIGGING DEPTH
3820MM
BACKHOE CAPACITY
0.3 M3
BUCKET CAPACITY
1.2M3
TYRE
16.9-28
DIGGING DEPTH
3820MM
CAB
PREVENT ROLL OVER CAB
LOADING LIFTING CAPACITY
2500KG
WEB SITE
HTTPS://WWW.MY-FORKLIFT.COM
Safety, durability, and operator comfort are fundamental pillars in the design of the 388H Backhoe Loader, ensuring not only high productivity but also long-term reliability and a superior working environment. The operator is housed within a certified Roll-Over Protective Structure (ROPS) cab, a critical safety feature designed to protect the operator in the unlikely event of a machine tip-over. This safety-certified cab, coupled with excellent all-around visibility, allows the operator to work with greater awareness and confidence. The intuitive control layout within the ergonomically designed cabin minimizes operator fatigue during long shifts, which directly translates to higher precision and sustained productivity throughout the workday. The powertrain is supported by renowned engine options, including the robust Yuchai YC4A105Z-T207 and other compliant models, ensuring dependable power delivery and adherence to emission standards. Every component, from the heavy-duty boom on the backhoe to the reinforced loader arms, is built with high-strength materials and subjected to rigorous quality control, guaranteeing that the 388H can withstand the daily rigors of professional use. This commitment to quality, safety, and operator-centric design makes the 388H Backhoe Loader a smart, long-term investment for any business seeking to enhance its operational capabilities and project success rates.
