ZGFORKLIFT / MYZG CPD20 2 Ton Lithium Electric Forklift
ZGFORKLIFT / MYZG CPD20 2 Ton Lithium Electric Forklift for Heavy-Duty Work
A high-capacity 2000 kg industrial machine engineered as a 2 ton lithium-ion electric forklift for strong starting torque, demanding outdoor yards, precise warehouse handling and intensive multi-shift logistics.
Overview: industrial 2 ton capacity with clean electric power
The ZGFORKLIFT / MYZG CPD20 is a high-performance lithium battery electric forklift developed by Shandong Zhuogong Machinery Equipment Co., Ltd. to combine diesel-class material handling capability with zero tailpipe emissions, low operating noise and reduced routine battery maintenance. It is intended for stone yards, machinery plants, timber operations, paper mills, logistics terminals and distribution warehouses.
Its high-voltage electric forklift architecture uses a 80 V/105 Ah lithium battery. The truck lifts a rated 2000 kg at a 500 mm load center with a 13 kW traction motor, 13 kW hydraulic pump motor, 110 mm ground clearance and 15% loaded gradeability. This combination supports demanding indoor and controlled outdoor work without exhaust fumes.
MYZG CPD20 factory technical specifications
The following table provides the complete mechanical, electrical, dimensional and operating data set for the CPD20 two-ton lithium electric counterbalance forklift. Final mast, fork, tyre, charger and attachment selections should be confirmed against the intended load and site conditions.
| Model | CPD20 (2 t series) |
| Power type | Lithium-ion battery |
| Rated lifting capacity | 2000 kg |
| Load center | 500 mm |
| Operator position | Seated operator |
| Overall length with forks | 3395 mm |
| Overall width | 1100 mm |
| Overhead guard/seat-to-guard height | 2020 / 980 mm |
| Maximum working height | 4110 mm |
| Standard/free lift | 3000 / 0 mm |
| Fork adjustment range | 260–1100 mm |
| Minimum turning radius | 2100 mm |
| 90-degree aisle width (1100×1100 pallet) | 3670 mm |
| Mast tilt forward/backward | 5° / 10° |
| Lifting speed unloaded/loaded | 325 / 250 mm/s |
| Travel speed unloaded/loaded | 15 / 14 km/h |
| Maximum gradeability with load | 15% |
| Unladen net weight | 2780 kg |
| Drive/steering wheels | 2 / 2 |
| Tyre type | Pneumatic |
| Front/rear tyre size | 6.50-10 / 5.00-8 |
| Service/parking brake | Foot / hand |
| Battery voltage and capacity | 80 V / 105 Ah |
| Traction motor power | 13 kW |
| Hydraulic pump motor power | 13 kW |
| Wheelbase/minimum ground clearance | 1520 / 110 mm |
| Front/rear overhang | 370 / 380 mm |
| Application environment | Indoor / controlled outdoor |
Engineering design and principal advantages
1. 80 V/105 Ah lithium system with 26 kW combined motor output
The lithium-ion battery system supports efficient power delivery and low-noise operation. The 13 kW traction motor and 13 kW hydraulic motor provide lifting speeds of 325 mm/s unloaded and 250 mm/s loaded, together with travel speeds of 15 km/h unloaded and 14 km/h at full rated load.
2. 110 mm ground clearance and a stable 2780 kg chassis
The 110 mm minimum clearance, 1520 mm wheelbase and pneumatic 6.50-10 front and 5.00-8 rear tyres support controlled indoor and outdoor routes. A 2780 kg unladen mass produces a stable footprint for pallet transport while the operator follows the approved load chart.
3. Compact 2100 mm turning radius and 260–1100 mm fork adjustment
The 1100 mm chassis width and 2100 mm turning radius help the CPD20 work efficiently in warehouse traffic lanes and production areas. Fork adjustment from 260 to 1100 mm supports different pallet widths. The mast reaches a 4110 mm maximum working height with a standard 3000 mm lift.
4. Low-maintenance lithium power and 15% loaded gradeability
The lithium battery requires no watering or routine gas ventilation and supports convenient opportunity charging when paired with the approved charger. The 15% loaded gradeability helps maintain productive movement on loading ramps and outdoor approaches. Actual runtime depends on load mass, route length, lift frequency, floor condition, ambient temperature and charging practice.
Recommended application environments
A 2000 kg capacity, generous ground clearance and zero tailpipe emissions make the CPD20 suitable for indoor production areas and demanding industrial yards when ventilation, floor loading, clearances and traffic controls have been evaluated.
Stone, concrete and building materials
Move granite packs, precast components, masonry blocks and heavy pallets between storage racks, processing lines, loading bays and gravel yard surfaces using suitable forks or approved attachments.
Heavy machinery plants and foundries
Handle castings, metal moulds, engines, dies and industrial components inside workshops or between covered production areas. Precise electric drive control assists positioning at machine tools, assembly stations and transport vehicles.
Paper mills, timber depots and logistics terminals
Transport large paper rolls, timber packs, plywood cases and export cargo during repeated shifts. Solid tyres can be considered for puncture-prone recycling or glass sites, while pneumatic tyres can improve ride comfort on uneven ground.
Frequently asked questions
What turning radius and aisle width does the CPD20 require?
The minimum turning radius is 2100 mm. The stated 90-degree stacking aisle for a 1100×1100 mm pallet is 3670 mm; always add practical safety clearance for the load, attachment, rack protection and operator skill.
How does 110 mm ground clearance help outdoors?
It reduces the risk of underbody and motor-housing contact when crossing small obstacles, rails, joints or uneven surfaces. It does not replace a site survey, speed control or the use of suitable tyres on rough ground.
What tyres and attachments are available for the CPD20? heavy-duty electric forklift
The documented pneumatic tyre sizes are 6.50-10 front and 5.00-8 rear. MYZG can discuss side shifters, fork positioners, clamps and rotators. Capacity may change with mast height, load center or attachment, so the final data plate and load chart must be confirmed.
Configure a ZGFORKLIFT / MYZG CPD20 for your operation
Send the maximum load, load dimensions, lift height, aisle width, door height, ramp gradient, working hours, indoor or outdoor conditions, local power supply and destination port. The factory team can prepare a suitable CPD20 configuration, attachment proposal, quotation, packing plan and international shipping option.
