Description
|
specifications |
|
|
Rated operating capacity(kg) |
1400 |
|
Bucket capacity(m3) |
0.6-0.7 |
|
Operationg weight(kg) |
4500 |
|
Max. travel speed(km/h) |
12/18 |
|
Hydraulic pump flow(L/min) |
75/130 |
|
Fuel tank capacity(L) |
85 |
|
Overall dimensions(mm) |
3850×1900×2150 |
|
Dimensions |
|
|
Height to bucket hinge pin(mm) |
3150 |
|
Width with bucket(mm) |
1880 |
|
Crawler width(mm) |
320 |
|
Crawler ground length(mm) |
1500 |
|
Ground clearance(mm) |
200 |
|
Engine |
|
|
Maker/Model |
WEICHAI WP4.1 |
|
Net power |
102hp/2400rpm |
|
Type |
turbocharged engine |
|
Displacement(L) |
4.1 |
