Description
| 动力 power | 柴油 | ||
|
操作方式 Operation mode |
座驾式 | ||
|
额定起重量 Rated lifting capacity |
Kg | 3800 | |
|
载荷中心距 Load center distance |
mm | 500 | |
|
前悬距 Front suspension |
mm | 500 | |
| 轴距 wheelbase | mm | 1730 | |
| 整机重量 Total weight | Kg | 4800 | |
| 轮胎类型 Tire type | 前/后 Before / after |
充气/充气 Inflation / solid |
|
| 轮胎 tyre | 前轮 front wheel | 28×9-15 | |
| 后轮 rear wheel | 6.50-10 | ||
| 轮距 Wheelbase | 前轮距 Front track | mm | 1000 |
| 后轮距 Rear track width | mm | 970 | |
| 全长 length | 无货叉 No fork | mm | 2808 |
| 有货叉 There are forks | mm | 3928 | |
| 全宽 wide | 车轮宽 Wheel width | mm | 1228 |
| 车架宽 Frame width | mm | 1220 | |
| 全高 high | 不起升门架高度 Not lifting the height of gantry | mm | 2204 |
| 护顶架高度 Height of roof guard | mm | 2100 | |
| 作业时最大高度 Maximum height during operation | mm | 4262 | |
|
最小离地间隙 Minimum ground clearance |
门架下端 Lower end of gantry |
mm | 135 |
| 车架中部（空/满） Middle of frame | mm | 165 | |
|
门架倾角 Gantry inclination |
° | 6/12 | |
|
自由起升高度 Free lifting height |
mm | 70 | |
|
标准起升高度 Standard lifting height |
mm | 3000 | |
| 货叉尺寸 Fork size | 厚*宽 Thick * wide | mm | 50×125 |
| 长度 标准/选配 Standard / optional | mm | 1070/1220 | |
|
最小转弯半径 Minimum turning radius |
mm | 2580 | |
|
最大行驶速度 Maximum driving speed |
满载/空载 Full load / no load | Km/h | 25.9/26.3 |
|
最大起升速度 Maximum lifting speed |
满载/空载 Full load / no load | Km/h | 360/400 |
|
满载最大挂钩牵引力 Maximum hook traction at full load |
KN | 16.7 | |
|
满载最大爬坡度 Maximum climbing gradient with full load |
% | 20 |
