Description
| Specifications | |
| Rated operating capacity(kg) | 700 |
| Tipping load(kg) | 1400 |
| Bucket capacity(m3) | 0.4 |
| Operationg weight(kg) | 2750 |
| Max. travel speed(km/h) | 12 |
| Hydraulic pump flow(L/min) | 50 |
| Fuel tank capacity(L) | 50 |
| Tires | 10.0-16.5 |
| Overall dimensions(mm) | 3380×1720×2050 |
| Dimensions | |
| Height at maximum extension(mm) | 3670 |
| Height to bucket hinge pin(mm) | 2900 |
| Width with bucket(mm) | 1740 |
| Track width(mm) | 1450 |
| Wheelbase(mm) | 991 |
| Ground clearance(mm) | 185 |
| Dump angle | 40° |
| Dumping height(mm) | 2310 |
| Maximum reach(mm) | 70 |
| Engine | |
| Model |
XINCHAI 490BPG（STAGE II） YANMAR(EURO III) |
| Net power | 36.7KW/2650rpm |
| Type | 4 Cylinder in-line, Water cooled, 4 stroke |
| Displacement(L) | 2.67 |
