CPDJ20 Lead acid forklift
48V Electric Forklift
In material handling, the last things you need are limitations. Utilizing different trucks for indoor and outdoor work creates inefficiencies that ultimately impact your bottom line. When you need raw power to tackle outdoor challenges and efficient, environmentally friendly operation indoors, look no further than MINGYU’s 48V Electric Pneumatic Forklift.
Special Features
2000 lb. Lifting Capacity
System of Active Stability (SAS)™
AC Drive & Lift Motors
Performance
An Operator’s Dream
Key Safety Features
According to demands, can be matched with different accessories
Model
CPDJ20
Rated load lifting capacity
2000kg
Load centre distance
500mm
Power style
Accumulator
Drive style
Sit down
Wheel base
1500mm
Tyre type
Pneumatic tyre
Number of wheels(front/rear)
2/2
Front wheel track
973mm
Rear wheel track
950mm
Tyre(front)
7.00-12.12PR
Tyre(rear)
18x7-8
Front overhang
448mm
Gantry angel (fron/rear)
6/12
Height of the gantry at landing
2050mm
Max lifting height
3000mm
Max height at working
4030mm
Overhead guard height
2140mm
Fork size
122x40x1070mm
Frame length
2360mm
Frame width
1160mm
Minimum turning radius
2010mm
Mast ground clearance （with full load）
110mm
Middle of frame ground clearance (with full load )
115mm
Right-angle channel width （pallet 1200X1200）
3930mm
Operating speed(without load/with full load)
13/14 mm/s
Lifting speed(without load/with full load)
260/355 mm/s
Gradeability with full loading
15%
Total weight(with accumulator)
4050 kg
Battery voltage capacity /5HR
48V/600Ah
Battery box size (width xlength xheight）
495x975x800 mm
Pull pump motor power
9kw
Oil pump motor power
11kw
Pull pump control style
MOS tube/Alternating current
Oil pump motor control style
MOS tube/Alternating current
Driving brake /Parking brake
Hydraulic /Machinery
Versatility For Any Operation
MINGYU designed and built AC Motors to power the 48V Electric Pneumatic to new levels of productivity and efficiency while delivering low-maintenance operation. Regenerative braking returns unused energy to the battery during operation. The multifunction display offers truck information right at your fingertips.
Add in completely programmable performance and power select capabilities to fine-tune your operation, and you have one powerful and versatile machine designed to increase your productivity and profitability.
Designed with the operator in mind, the 48V Electric Pneumatic comes equipped with amenities to help do their job quickly and efficiently. Standard mini-lever controls offer comfortable and ergonomic material handling while minimizing movement.* Mast options with excellent visibility, an adjustable, slim steering column, and a low dashboard, deliver excellent visibility during travel and load handling.
An automatic parking brake engages when the truck stops and disengages when the driving direction is selected and the accelerator is pressed. Standard wet disc brakes deliver smooth, powerful stopping power with minimal maintenance costs. Hydraulic power steering provides a 100° steering angle and comes with steering synchronization to maintain steering wheel alignment. Standard automatic parking brakes engage when the truck stops and disengage when the driving direction is selected, and the accelerator is pressed. *
Durability, Reliability, & Value
Built using the MINGYU Production System, this 48V Electric Pneumatic Forklift gives operators the highest levels of quality, durability, and reliability of internal combustion trucks, with the speed and economic advantages of an electric forklift. This forklift can operate indoors and out while protecting operators from the elements.
