ZGFORKLIFT / MYZG CPD15 1.5 Ton Lithium Electric Forklift
CPD15 1.5 Ton Lithium Electric Forklift
ZGFORKLIFT / MYZG — ZGFORKLIFT / MYZG CPD15 1500 kg lithium electric forklift from Shandong Zhuogong Machinery equipment Co.,Ltd, designed for warehouses, distribution centers and industrial material handling.
The ZGFORKLIFT / MYZG CPD15 combines a 1500 kg rated capacity with lithium battery power for pallet transport, shelf replenishment, production supply and loading work. Its seated layout is suitable for warehouses, distribution centers, factories and controlled logistics areas where low noise, efficient charging and predictable operation are important.
The documented lithium configuration uses an 80 V / 105 Ah battery and a 500 mm load center. Runtime and charging depend on load, lift frequency, travel distance, floor, slope, temperature, charger and operator practice. The final mast, lift height, battery, charger, forks and tyres must be confirmed in the approved technical sheet.
The CPD15 lithium-ion electric forklift represents a significant advancement in industrial material handling technology, specifically engineered to meet the rigorous demands of modern warehouse and distribution center operations. Powered by an advanced 80V/105AH lithium-ion battery system, this forklift delivers exceptional energy efficiency and extended operational runtime while minimizing maintenance requirements. With an impressive rated load capacity of 1500kg at a 500mm load center distance, this robust machine is designed to handle standard palletized goods with remarkable stability and precision. The ergonomic sit-down driving configuration provides operators with enhanced comfort during prolonged shifts, while the 2100mm overall height (with mast lowered) and 2020mm overhead guard ensure safe operation in various industrial environments. The machine's dimensions—2800mm length with forks and 1130mm width—allow for excellent maneuverability in confined warehouse aisles, complemented by a well-balanced 1285mm wheelbase that contributes to superior handling characteristics. What distinguishes the CPD15 is its intelligent integration of power, performance, and operator-focused design, creating an optimal solution for businesses seeking to enhance their material handling efficiency without compromising on reliability or workplace safety.
Performance capabilities of the CPD15 electric forklift demonstrate exceptional engineering in real-world operational scenarios. The forklift achieves a substantial standard lifting height of 3000mm with an 80mm free lift capability, enabling operators to efficiently manage multi-level storage systems and high stacking requirements. The lifting mechanism operates at impressive speeds, reaching 430mm/s when unloaded and maintaining 360mm/s even at full 1500kg capacity, ensuring minimal cycle times during intensive material handling operations. Travel performance is equally noteworthy, with maximum speeds of 15km/h unloaded and 14km/h fully loaded, facilitating swift material movement across expansive warehouse floors. The 15% maximum gradeability ensures reliable performance on ramps and inclined surfaces, while the compact 1800mm turning radius and 3570mm minimum right-angle channel width requirement for standard pallets make this forklift exceptionally agile in space-constrained warehouse layouts. The pneumatic tire configuration (21x8-9 front, 16x6-8 rear) provides excellent traction and shock absorption on various surfaces, while the comprehensive braking system—featuring both foot-operated service brakes and a hand-operated parking brake—offers precise control and enhanced safety. These technical specifications translate directly into operational advantages, including increased throughput, reduced handling time, and improved safety across diverse industrial environments.
The engineering excellence of the CPD15 extends to its sophisticated drivetrain and hydraulic systems, which ensure consistent performance under demanding conditions. Powered by an 11Kw drive motor and supported by a 13Kw oil pump motor, this electric forklift delivers reliable power transmission even during peak load handling. The 2/2 wheel configuration (two driving wheels and two steering wheels) optimizes power distribution and steering precision, while the mast tilt capability of 6 degrees forward and 10 degrees backward provides secure load handling during stacking, retrieval, and transport operations. With 115mm minimum ground clearance, the forklift navigates smoothly over minor floor irregularities commonly encountered in warehouse settings. The unladen weight of 2900kg contributes to the machine's stability during operation, while carefully engineered overhangs (370mm front, 230mm rear) and wheel tracks (960mm front, 950mm rear) optimize weight distribution and turning characteristics. These meticulously designed features work in harmony to create a material handling solution that not only meets but exceeds industry standards for durability, efficiency, and operational safety in challenging warehouse and industrial applications.
Operational efficiency and lifecycle value further distinguish the CPD15 electric forklift in the competitive material handling equipment market. The lithium-ion battery technology offers substantial advantages over traditional power sources, including faster charging capabilities, longer operational cycles between charges, and reduced total cost of ownership through extended battery life and minimal maintenance. The comprehensive safety features, combined with intuitive operator controls and excellent visibility, minimize training requirements while maximizing productivity. The forklift's design facilitates straightforward access to maintenance points, reducing service downtime and associated operational costs. With its robust construction, advanced power management systems, and user-centric design philosophy, the CPD15 represents a forward-thinking investment for operations seeking to elevate their material handling capabilities. Whether deployed in manufacturing facilities, distribution centers, logistics operations, or retail warehouse environments, this electric forklift delivers the performance, reliability, and efficiency necessary to maintain competitive advantage in today's fast-paced industrial landscape, establishing itself as an indispensable asset for modern warehouse and supply chain management.
Before ordering, provide pallet dimensions, maximum load, lift height, aisle width, doorway height, ramp gradient, daily hours, indoor or outdoor use, ambient temperature, electrical supply and destination port. These details allow the factory to match the truck to the real duty cycle.
Safe operation requires trained personnel, daily inspection and a controlled work zone. Check forks, chains, mast, hoses, tyres, brakes, steering, alarms, battery and charger. Travel with forks low, slow before turns, keep people away from raised loads and never exceed the approved capacity.
Preventive maintenance includes cleaning, mast lubrication, chain and roller inspection, hydraulic checks, fastener inspection and battery care. Use only the approved charger, keep electrical parts dry and stop operation if abnormal heat, smell, swelling, leakage or warnings appear.
